PERKINS MF - LANDINI

SE REF ENGINE # PART # DESCRIPTION
3 Cylinder Crankshafts
1101 31312436
3.152 ROPE
152 C.I.D.
2.5 LITER
3 CYL.		 31312436; 026005M1;
736532M91; 31312419; 84402;
31312436; SD260034; 31312441;
U5BG0031; 31312700; ZZ90084;
3637454M91; ZZ90116; 467;
ZZ90148		 KEYED NOSE. ROPE SEAL
AGRICULTURAL: MF-35, 135, 148, 230, 240, 250, 254,
254S, 255, 350, 353, 355, 360, 363, 550
INDUSTRIAL: MF-20B, 20D, 20E, 20F, 30E, EPH, 40, 40E
MF-LANDINI C4500, R-DT5500
1666 3.152. 3 CYL. 84399; 31312437 SPLINED NOSE. ROPE SEAL
1729 3.152; D3.152
3 CYL.		 ZZ90148; ZZ90116;
3638309M91; 84402		 KEYED NOSE. ROPE SEAL
FITTED WITH COUNTER WEIGHT, WASHER & SCREW
ALSO AVAILABLE WITH NOSE GEAR
1102 31312701
3.152 LIP
152 C.I.D.
2.5 LITER
3 CYL.		 026053M; 94458; 31312701;
94464; 31312707; U5BG0027;
31315135; ZZ90078;
3637410M91; ZZ90150;
ZZ90122; 637399M91		 KEYED NOSE. LIP SEAL
AGRICULTURAL: MF-135, 148, 230, 240, 250, 254, 254S,
255, 350, 353, 355, 360, 363, 550
INDUSTRIAL: MF-20B, 20D, 20E, 20F, 30E, 30H, 40, 40E
MF LANDINI C4500, R-DT5500
1667 3.152
3 CYL.		 31312702; 31312704; 94463;
94459; ZZ90117		 SPLINED NOSE. LIP SEAL
1730 3.152
3 CYL.		 3132.0002K96/3 KEYED NOSE. LIP SEAL
FITTED WITH COUNTER WEIGHT, WASHER & SCREW
ALSO AVAILABLE WITH NOSE GEAR
1888 PERKINS 1103
CRANKSHAFT		 1103 / 1103B-33 / 1103C-33 / 1103C-33T
4181V017 - PERKINS DIESEL		 LIP SEAL. 3 PULLEY HOLES.
6 + 1 FLANGE HOLES. 3 CYL.
1889 3.152
3 CYL. 		84399; 31312437 SPLINED. ROPE. WITH COUNTER WEIGHT
ALSO AVAILABLE WITH NOSE GEAR
1890 3.152
3 CYL. 		31312702; 31312704; 94463;
94459; ZZ90117		 SPLINED. LIP. WITH COUNTER WEIGHT
ALSO AVAILABLE WITH NOSE GEAR
4 Cylinder Crankshafts
1834 31315824
4.108 ROPE
107 C.I.D.
1.8 LITER
4 CYL.		 31315824; ZZ90124;
84417; U5BG0056		 ROPE SEAL
445, 4600M, L555 SKID LOADER
E146 LOADER, M434-4 TRENCHER
INDUSTRIAL, MARINE
1103 31315145
4.203 ROPE
203 C.I.D.
3.3 LITER
4 CYL.		 026008MI; 3638473M91;
31315135; 742742M91;
31315138; 84407; 31315145;
85811; 31315148; 92484;
31315167; 92485; 31315184;
U5BG0017; ZZ90121; U5BG0028;
3637399M91		 KEYED NOSE. ROPE SEAL
A4.203, AD4.203, AG3.152 GAS
MF-65, 150, 155, 158, 165, 650, 765,
MF-INDUSTRIAL 50, LANDINI
PERKINS, 192, A4, R-DT6000
1668 4.203; D4.203
4 CYL. 		SPLINED NOSE. ROPE SEAL
1104 31315184
4.203 LIP
KEYED NOSE
203 C.I.D.
3.3 LITER		 026032M1; 94441; 31315182;
94454; 31315184; 94455;
742344M91; ZZ90111; 026033;
3637458M91		 KEYED NOSE. LIP SEAL. 4 CYL.
A4.203, AD4.203
MF-65, 155, 158, 165, 650, 765
MF-INDUSTRIAL 50, LANDINI
PERKINS A4.203, R-DT6000
1669 31315181
4.203 LIP
SPLINED NOSE
203 C.I.D.
3.3 LITER		 026032M1; 94441; 31315181;
94454; 31315182; 94455;
31315184; ZZ90111; 742344M91		 SPLINED NOSE. LIP SEAL. 4 CYL.
HYSTER CHALLENGER 860C FORKLIFT
1105 4.236 / 4.248
4 CYL.
HEAVY WEIGHT 		3637789M91; U5BG0054;
31315911; 31315912; 84422;
85721; ZZ90093; 84421; 94434;
7340893M1; 31315851;
68050; 31315884		 SPLINED NOSE. ROPE SEAL. EW
MF 178, 185, 188, 194-F, 285, 294S-4S, 393, 397
MF INDUSTRIAL 50E/EX, 60H, 60H "S" SERIES
MF LANDINI R-DT8500, C7800, C7830
PERKINS A4.248, 4.248
1106 4.236 / 4.248
4 CYL.
HEAVY WEIGHT 		3637401M91; U5BG0024;
31315981; 31315982; 31315991;
94435; 94436; ZZ90082;
ZZ90081; ZZ90143; 741747M1		 SPLINED NOSE. LIP SEAL. EW
MF 265, 274, 274S, 274SK, 275, 285, 284S-4S, 365, 373,
375, 377, 383, 387, 565, 575, 675, 3050, 194-F, 285,
294-S-4S, 393, 397, 178, 185, 188 MF LANDINI R-DT6550,
MF LANDINI R-DT8500 PERKINS A4.236, PERKINS A4.248,
C6830, R-DT7550, R-DT7530F 4.248 MF COMBINES 440,
MF INDUSTRIAL 50, 50B, 50E/EX 50H/HX, 50H/HX'S'SERIES
MF INDUSTRIAL 50E/EX, 60H, 60H'S' SERIES
1769 4.236 / 4.248
4 CYL.
HEAVY WEIGHT 		ZZ90202; ZZ90081;
364040M91; 3665768M2		 SPLINED NOSE. LIP SEAL. EW
12 FLANGE HOLES
1770 4.236 / 4.248
4 CYL.
HEAVY WEIGHT 		364040M91; 3665768M2 SPLINED NOSE. LIP SEAL. EW
12 FLANGE HOLES. 3 PULLEY HOLES
1107 4.236 / 4.248
4 CYL.
LIGHT WEIGHT 		31315911; 31315912; 84422;
85721; ZZ90093; 736829M91;
ZZ90108; 3637789M91;
3639541M1		 SPLINED NOSE. ROPE SEAL
MF 168, 175, 178, 185, 188, 265, 274, 274S, 274SK, 275,
285, 284-4S, 365, 373, 375, 377, 383, 387, 565, 575, 675,
3050. MF LANDINI R-DT7500, R-DT6550, C6830, R-DT7550,
R-DT7530F, PERKINS 4.236; A4.236 MF COMBINES 440,
MF INDUSTRIAL 50, 50B, 50E/EX, 50H/HX 'S' SERIES
1670 4.236 / 4.248
4 CYL.
LIGHT WEIGHT 		U5BG0026; 31315664 SPLINED NOSE. ROPE SEAL
3 PULLEY HOLES
1108 4.236 / 4.248
4 CYL.
LIGHT WEIGHT 		31315871; 31315631; 31315641;
31315664; 85821; 94433; 94434;
26042; 26046; U5BG0052;
ZZ90122; ZZ90082; 736829M91;
741750M1; UR040591/3		 SPLINED NOSE. LIP SEAL
MF 158, 175, MF LANDINI R-DT7500
1736 4.236 / 4.248
4 CYL.
LIGHT WEIGHT 		ZZ90143; 3641031M91 SPLINED NOSE. LIP SEAL
3 PULLEY HOLES
1737 4.236 / 4.248
1004 SERIES
4 CYL.
LIGHT WEIGHT 		ZZ90119; ZZ90202;
PHASER 90 ENG.		 LONG NOSE. SPLINED. LIP SEAL
3 PULLEY HOLES
1551 4.212; D4.212 85719; ZZ90100; ZZ90076;
3637457M91; 737189M91		 KEYED / SPLINED NOSE. ROPE SEAL
MF 165 WITH A4.212. 4 CYL.
1552 4.212; D4.212 94430; ZZ90077; 3637453M91;
742873M91		 KEYED / SPLINED NOSE. LIP SEAL
MF 165 WITH A4.212. 4 CYL.
1662 Te20, MF35, 135 825216M1 PETROL MODEL
1709 TEF20 DIESEL
MF35; 23C DIESEL		 302205; 1884134M91 4 CYL.
1790 NEW 1004.4T PHASER 135 TI; 110 TI; ZZ90145 LIP SEAL. 3 PULLEY HOLES. 4 CYL.
1791 4.236 / 4.248
4 CYL.		 31315661
HEAVY WEIGHT		 SPLINED NOSE. LIP SEAL. EW
6 + 1 FLANGE HOLES. 3 PULLEY HOLES
1798 Y.236
4 CYL.		 ZZ90082
HEAVY WEIGHT		 SPLINED NOSE. ROPE SEAL. EW
6 + 1 FLANGE HOLES. 3 PULLEY HOLES
1820 PERKINS 1004G;
SERIES 1004-4		 ZZ90238
4.236; 4.248		 NEW 1000 SERIE; 1004-40; 1004-42; 100 SERIE EW
4 CYL.
1835 4.236 / 4.248
SUPERCEDE
VERSION		 31315993 SPLINED NOSE. ROPE SEAL. HEAVY CRANKSHAFT
4 CYL.
1836 4.236 / 4.248
1004 / 1004.42
SERIES		 ZZ90202
NEW PHASER VERSION		 SPLINED NOSE. LIP SEAL
3 PULLEY HOLES. 4 CYL.
ALSO AVAILABLE IN HEAVY CRANKSHAFT VERSION
1837 4.236 / 4.248
1104 SERIES		 NEW VERSION
ELECTRONIC ENGINE		 LONG NOSE. SPLINED. LIP SEAL
3 PULLEY HOLES. 4 CYL.
ALSO AVAILABLE IN HEAVY CRANKSHAFT VERSION
1838 4.236 / 4.248
TURBO ENGINE		 ZZ90212 SPLINED NOSE. LIP SEAL. 10 FLANGE HOLES
3 PULLEY HOLES. TUFFTRIDED. 4 CYL.
1839 1004 / 1104
SERIES		 ZZ90222 SPLINED NOSE. LIP SEAL. 10 + 1 FLANGE HOLES
3 PULLEY HOLES. HEAVY CRANKSHAFT. 4 CYL.
TIMING RING FITMENT PROVISION
1710 1 THRUST PLATE
3 BOLTS		 SUITABLE FOR 4.248/4.236/6.354 CRANKSHAFT
1851 PERKINS 400
SERIES		 404C-2.2
OEM NO.: 115256990		 STROKE : 100 mm. 4 CYL.
1852 PERKINS 1004
TURBO ENGINE		 PHASER SERIES. ZZ90212 SPLINED NOSE. LIP SEAL. 3 PULLEY HOLES.
10 + 1 FLANGE. NITRIDING. 4 CYL.
1853 PERKINS 1004/1104
SERIES		 1004/1104 SERIES SPLINED. LIP. 3 PULLEY HOLES. 10 + 1 FLANGE.
WITH TIMING RING FITMENT PROVISION. 4 CYL.
1854 PERKINS 400
SERIES		 404C-2.2
OEM NO.: 115256750		 STROKE : 90 mm. 4 CYL.
1862 PERKINS ZZ90093 MF # 3639541M1; JCB # 02101158 SPLINED. LIP SEAL. 3 PULLEY HOLES. 10 + 1 FLANGE. 4 CYL.
1921 PERKINS MF
1004.4; 1004.40		 PERKINS :
ZZ90239; 4225085M91;
AD-104082; 1004.4 1004.40
ZZ90222; ZZ90237; ZZ90239
MF :
OEM : 4225085M91;
4226955M91; 4227020M91
TRACTOR : 3435 VSF 3445 VSF
3455 VSF 5425 5435 5445 5455
5460 6445 6455		 SPLINED NOSE. 3 PULLEY HOLES
LIP SEAL. 6 + 1 FLANGE HOLES
WITH TIMING RING WEB
REF : GM1123
4 CYL.
1922 PERKINS ZZ90239 PERKINS 1104
ORIGINAL REF : ZZ90239		 SNOUT : 3 HOLES, SPLINED, KEYED
FLANGE : LIP SEAL. 10 HOLES, 1 DOWEL
WITH SEPARATE TIMING RING FITMENT WEB. 4 CYL.
1927 NEW PERKINS 1104
BIG END Ø
69.4 mm		 PERKINS 1104. 4 CYL.
69.4 mm BIG END Ø		 SNOUT : 3 HOLES, SPLINED, KEYED
FLANGE : LIP SEAL. 10 HOLES, 1 DOWEL
1935 ZZ90222; ZZ90239
NEW LATER
VERSION		 LONG WEB CRANKSHAFT
232-7400, ZZ90224, 4225086M91,
4225085M91, 1-153		 SPLINED. 3 PULLEY HOLES. LIP SEAL. 10+1 FLANGE HOLES.
WITH SEPARATE TIMING RING. 4 CYL.
1936 ZZ90222; ZZ90239
TIMING RING
NEW LATER
VERSION
LONG WEB CRANKSHAFT
232-7400, ZZ90224, 4225086M91,
4225085M91, 1-153		 LOOSE TIMING RING.
1932 3054.
New Later Version
 Long Web Crankshaft
Splined. 3 Pulley Holes. Lip Seal.
6 Flange Holes.
4 Cyl.
1933 3054C/E. C4.4T.
C4.4T/TA
New Later Version
 Long Web Crankshaft
Naturally Aspirated / Turbo
Splined. 3 Pulley Holes. Lip Seal.
10+1 Flange Holes.
With Separate Timing Ring. 4 Cyl.
1934 3054C/E. C4.4T.
C4.4T/TA
Timing Ring
 Long Web Crankshaft
New Later Version
Loose Timing Ring.
1950 Caterpillar 1004
 Part # 2327400-ZZ90239
Keyed - 3 Pulley Holes.
Flange : 10 Holes, 1 Dowel.
4 Cyl.
1951 Caterpillar 1004
 Part # ZZ90237
Keyed - 3 Pulley Holes.
Flange : 10 Holes, 1 Dowel.
4 Cyl.
1952 Caterpillar C4.4
Industrial Engine
Caterpillar
Crankshaft Model :
C4.4 Engine -
Machine 444
Configuration :
C4.4 Industrial
Engine 44400001-
UP
Product : Engine
- Machine
 Specifications :
C4.4 Industrial Engine.
Middle Number - RENR9961-02
Keyed - 3 Pulley Holes.
Flange : 10 Holes, 1 Dowel
With Timing Ring Fitment Web.
Loose Timing Ring Available.
4 Cyl.
1964 Perkins /
Caterpillar
Timing Gear
Web
 Perkins, Caterpillar 1104-Srs,
3054C, 3054E Crankshaft 4-Cyl.
3 Pulley Holes. 10+1 Flange Holes
OEM / Part Numbers :
ZZ90239, 232-7400, ZZ90222,
ZZ90239, 072-156, 072-106,
072-140
1946 BADSUN
NEW 1004.4T
 135 TI; 110 TI.
HEAVY WEIGHT FORGING		 NEW 1004.4T. IRAN MODEL. 4 CYL.
1967 PERKINS PK 4.318 31315952, 31315843, 31315971
31316323, 31316324, 31316325		 4 CYL.
1968 PERKINS A4.318 DIESEL PERKINS ENGINE A4.318 DIESEL
MASSEY FERGUSON # MF285, MF1085		 4 CYL.
6 Cylinder Crankshafts
1109 6.305 31323146; 84433; 026020N KEYED NOSE. ROPE SEAL. 6 CYL.
1690 6.305 KEYED NOSE. LIP SEAL. 6 CYL.
1553 6.354.4
6 CYL.		 U5BG0037; ZZ90113;
3637408M91		 KEYED NOSE. ROPE SEAL. MF 399, 699, 1014, 1114, 1134,
1250, 2620, 2640, 2645, 2680, 2685, 2720, 2725, 3080,
3090, 3650 MF COMBINES 24, 27, 29, 29XP, 31, 530, 535,
560, 565, 620, 625, 660, 665, 750, 800, 805, 825
MF LANDINI R-DT1000, R-DT100005, R-DT12500,
R-DT1300 MKII, R-DT14500 MKII, PERKINS A6.354.4,A6.372.4
1775 6.354.4 ZZ90196 KEYED NOSE. ROPE SEAL. 3 PULLEY HOLES. 6 CYL.
1741 6.354.4
6 CYL.		 31314021; 313111021; 68076;
ZZ90086; 3637404M91;
ZZ90113; 748751M1		 KEYED NOSE. LIP SEAL. MF 2705, 3525, 3545, 3630,
3650 MF COMBINES 550, 750, 760, 850, 860
MF LANDINI R-DT14500, PERKINS A6.354.4, T6.354.4
1554 6.354.4; 6 CYL. U5BG0035; 313H021 KEYED NOSE. LIP SEAL; 3 PULLEY HOLES
1560 6.354.4 ZZ90105; 3131H022 KEYED NOSE. LIP SEAL. TUFFTRIDED. 6 CYL.
1776 6.354.4
6 CYL.		 U5BG0038; 3637406M91;
4224054M91		 KEYED NOSE. LIP SEAL. 3 PULLEY HOLES
TUFFTRIDED
1671 1006 PHASER
SERIES		 3637019M91; ZZ90218 KEYED NOSE. LIP SEAL. 3 PULLEY HOLES
WITHOUT GEAR COLLAR STEP. 6 CYL.
1110 6.354.2
6 CYL.		 31322361; 31322316; 31322317;
31322363; 31322364; 68063;
85727; 68063; ZZ90089;
U5BG0045; 742150M1; 736902M1		 SPLINED NOSE. ROPE SEAL. MF 1100, 1014, 1200
MF COMBINES 500, 510, 515, 520, 525, 620, 625
MF LANDINI R-DT9500, R-DT10000, R-DT10005
PERKINS A6.354, PERKINS A6.354.1, A6.354.2, A6.372.1
1555 6.354.2
6 CYL.		 31323261; 31323262; 94468;
94460; 94443; ZZ90090;
U5BG0048; 742160M1; 742161M1		 SPLINED NOSE. LIP SEAL. MF 1100, 1014, 1200
MF COMBINES 500, 510, 515, 520, 525, 620, 625
MF LANDINI R-DT9500, R-DT10000, R-DT100005,
PERKINS A6.354, A6.354.1 A6.354.2, A6.372, A6.372.1
1701 PERKINS 6.358
6 CYL.		 635855 SPLINED NOSE. LIP SEAL
HEAVY DUTY CRANKSHAFT
1789 PERKINS 1106 PHASER 180TI; 6.354 PHASER
3638402M91; ZZ90085; ZZ90087		 KEYED NOSE. LIP SEAL. 3 PULLEY HOLES. 6 CYL.
1806 6.305 EBRO TRACTOR LIBYA MODEL. SPLINED. LIP SEAL. 6 CYL.
1840 PERKINS
4225497M1		 PERKINS : ZZ90213
MF : 3637019M91		 KEYED NOSE. LIP SEAL. 3 PULLEY HOLES. 6 CYL.
WITH SEPARATE TIMING RING
1887 1106 SERIES
TIMING RING		 PERKINS. 3116L002/159 LOOSE TIMING RING
1953 Perkins 1106 Perkins # ZZ90228
Nitrided.
With Separate Timing Ring.
6 Cyl.
1954 Perkins 1106 Perkins # ZZ90229
Nitrided. 6 Cyl.

All parts listed are STYR parts, and are not manufactured by the original equipment manufacturer unless otherwise stated. Original Equipment names, part numbers and descriptions are quoted for reference purposes only, and are not listed to suggest that they are made by the original equipment manufacturer.

© STYR 2021

Design by SNM
